輸入特性（INPUT CHARACTERISTICS）：

2.1輸入電壓(Input Voltage):

 額定電壓(Nominal Voltage):220Vac

 調整范圍（Variation Range):100-240Vac

2.2輸入頻率（Input Frequency）:

     額定頻率（Nominal Frequency）:50/60Hz

     調整頻率（Variation Frequency）:47-63Hz

2.3最大輸入電流(Max Input Current):

  當輸入交流電壓為額定值的下限時,輸出電壓負載滿載，最大輸入交流電流3.5A。

3.5Arms max At any input voltage and rated, DC output rated load.

2.4浪涌電流(Inrush Current):

當輸出為額定負載，環境溫度為25℃，輸入220Vac冷態起動電源時的最大浪涌   電流小于50A。

50Amps Max. Cold start at 220Vac input, with rated load and 25℃ambient.

輸出特性（OUTPUT CHARACTERISTICS）：

3.1輸出功率(Power Output);

      空載電壓      最大充電電流          轉燈電流        最大輸出功率

      Voltage        Charging Current    Turn Lamp Current    Output Power

      29.4V             5A                 0.5A             147W

3.2負載特性/調整率(Combined Load/Line Regulation):

       浮充電壓      最大充電電壓   線性調整        負載調整

       Voltage    Max.Charge Voltage  Line Regulation   Load Regulation

       29.4V             29.4V         ±1%           ±5%

   3.3效率(Efficiency):

      當輸入220Vac和輸出最大負載時,最小90 %。

        90%Min.At 220Vac input and output Max. Load.

 保護功能(PROTECTION REQUIREMENT):

4.1短路電路保護（Short Circuit Protection）:

      該電源在供電時短路解除時,能恢復正常工作。

The power supply will be auto recovered when short circuit faults remove.

4.2過流保護(Over current Protection)：過流故障排除后，電源將自動恢復正常工作。

      The power supply will be auto recovered when over current faults remove.

4.3過壓保護(Over Voltage Protection)

      當輸出電壓超過額定電壓時,電源將保護,故障排除后能恢復正常工作。

The power supply will be auto recovered when faults remove.

 環境要求(ENVIRONMENTAL REQUIREMET):

5.1工作溫度(Operating Temperature):

    -20℃~+45℃,滿載,正常工作。

5.2儲存溫度(Storage Temperature):

  -20℃至85℃,帶外殼(With package).

安全及EMC要求(SAFETY AND EMC REQUIREMENT):

6.1安全: 符合EN60950

6.2充電示意圖：
